24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker

24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker

  • 24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker
  • 24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker
24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: TY-20 24
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Type: DC Power Surge Protector 24VDC Class: Class II
Connection Mode: +/-/PE Item Name: DC Surge Protective Device
Material: Thermal Plastic UL94-V0 Un: DC 24V
Uc: DC 36V Pole Number: 2P
Tu: -40℃-80℃ Standard: IEC61643-1
High Light:

20kA Pluggable Surge Protective Device

,

24V Pluggable Surge Protective Device

,

20kA spd circuit breaker

24V DC Surge Protector 20kA Surge Protective Device Type 2 T2 Class C Class II Pluggable Lightning Protection



24V DC Surge Protector 20kA Surge Protective Device Feature:

Plug-in module design, easy replacement.
No leakage, no operating currents
Visual Indication: Green=OK, Red=Replace.
High energy anti-surge components MOV
Remote alarm contact to make status monitoring easy.
State-of-the-art surge protection technology
Quick thermal response for self-protection.
DIN rail mounting
Voltage protection level (Up): 0.3kV.
With temperature control circuit breaker and built-in over current protective circuit, the modular SPD can automatically release to avoid fire danger when it breaks down.
Type 2, T2, Class C, Class II, In (8/20μs): 10kA, Imax (8/20μs): 20kA.
DC surge protector is designed to protect equipment connected to DC power supplies from lightning surges.
Un dc: 24Vdc.
Uc dc: 36Vdc.
This SPD is designed and tested according to DC Type 2 classification from IEC 61643-11 / EN 61643-11 / EN 50539-11 standard.



24V DC Surge Protector 20kA Surge Protective Device Product detail:



2 Mod TY-20 24
SPD classification according to IEC61643-1 Class II
Operating Voltage                                    Un DC 24V
Max. Continuous Operating Voltage        Uc DC 36V
Nominal discharge current (8/20us)          In 10kA
Max. discharge current (8/20us)           Imax 20kA
Voltage protection level                           Up <300V
Response time                                          tA ≤25ns
Operating temperature range                   Tu -40℃-80℃
Operating state / fault indication green / red
Technology MOV
Format Plug-in modular
Protection Mode +/PE,-/PE
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermal plastic UL94-V0
Degree of protection IP20
Standards compliance    IEC 61643-11 / EN 61643-11 / UL1449 ed.4/GB 18802.1



24V DC Surge Protector 20kA Surge Protective Device Product view:

24V 20kA Type 2 T2 Class C Pluggable Surge Protective Device SPD Circuit Breaker 0

24V DC Surge Protector 20kA Surge Protective Device Application:

Type 2 DC surge arresters/SPD is designed to protect DC load current, installs at or within equipment such as DC servo mechanisms, fire alarm monitoring systems, security system controls, telecom and data com systems, microwave communication system, etc. to provide compact, heavy duty surge suppression.
It is mainly applicable for the Direct Current surge protection and over voltage protection in the fields of low voltage DC power supply.
It is connected in parallel on the line to be protected.

24V DC Surge Protector 20kA Surge Protective Device Advantage:

• Module designed.
• No follow currents.
• High MOV resistance.
• Color is customizable.
• Logo is customizable.
• 35mm din rail mounted.
• High discharge capacity.
• Package is customizable.
• Mechanical Status Indicator.
• Easy changing of the surge protection module.
