ethernet surge protection devices RJ45 Arrester Ethernet Networking Surge Protector
1.Applicable scope
Power over Ethernet lines for the data lines and power supply to carry out complex lightning surge protection devices. Make sure your systems and equipment from electrostatic discharge due to lightning or surges caused damage.
Main features
1,Flow capacity, fast response
2,Multi-level protection circuit, residual depression
3,Use the core components of international brand products, excellent performance
4,Take place through the special treatment to avoid signal interference network SPD
Ethernet Networking Surge Protector Product Details:
| |
BRRJ45H-8L |
| Test standards |
IEC61643-21 |
| Nominal voltage Un |
5V |
| Max.continuous operating d.c.voltage Uc |
6V |
| Max.continuous operating a.c.voltage Uc |
4V |
| Nominal current IL |
0.5A |
| C2 Nominal discharge current (8/20us) per line In |
5kA |
| Voltage protection level [line-line] Up |
≤30V |
| Voltage protection level [line-PG] Up |
≤500V |
| Response time [line-line] tA |
≤1ns |
| Response time [line-PG] tA |
≤100ns |
| Operating temperature range Tu |
-40℃…+80℃ |
| Connection (input/output) |
RJ45 socket 8 line |
| Data rates |
1000 Mbps |
| Insertion Loss |
≤0.3dB |
| Enclosure material |
aluminium alloy |
| Degree of protection |
IP20 |
Application:
to prevent indirect lightning or direct lightning impact and network over-voltage damage to signal equipment.
Company information:
Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs. Such as ac surge protector, dc surge protection, LED lighting surge arrester, data surge protective device and so on. Our company is located in Yueqing, Zhejiang, China. Britec Electric Wenzhou Co., Ltd. was established in 2003.We are providing quality products, competitive price, prompt delivery and excellent service, and looking forward to even greater cooperation with overseas trade based on mutual benefits.
Certificate:
We got CB, CE, TUV,RoHS Certificate:
Payment & Shipping:
FAQ:
Q1:Are you a lightning surge protectors factory or lightning surge protectors trading company?
A1: We are lightning surge protectors manufacturer.
Q2: Warranty and return:
A2:1. Warranty 5 years
2. lightning surge protectors products and accessories have been tested 3 times before ship out.
3. We own the best after-sale service team, if any problem happens, our team will do our best to solve it for you.
Q3: How can I get some lightning surge protectors samples?
A3: We are honored to offer you lightning surge protectors samples, pls contact our staff and leave detailed contact information.
Q4: Is sample available and free?
A4: Sample is avaible, but the sample cost should be pay by you.The cost of sample will be refund after further order.
Q5:Do you accept customized order?
A5:Yes, we do.
Q6: What's the delievery time?
A6:It usually takes 7-15days after confirming payment, but specific time should be based on the order quantity.
