2P 40KA UL Certified 24v Surge Protector Thermoplastic Material

2P 40KA UL Certified 24v Surge Protector Thermoplastic Material

  • 2P 40KA UL Certified 24v Surge Protector Thermoplastic Material
  • 2P 40KA UL Certified 24v Surge Protector Thermoplastic Material
2P 40KA UL Certified 24v Surge Protector Thermoplastic Material
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: TY-40 24
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Type: DC Power Surge Protector 24VDC Class: Class II
Connection Mode: +/-/PE Item Name: DC Surge Protective Device
Material: Thermal Plastic UL94-V0 Un: DC 24V
Uc: DC 36V Max. Discharge Current: 40kA
Voltage Protection: ≤300V Standard: IEC61643-1
High Light:

UL Certified 24v surge protector

,

40KA 24v surge protector

,

Thermoplastic 40ka surge arrester

DC 24v Surge Protector 2P 40KA Lightning Arrester UL Certified SPD Surge Protective Device​



DC 24v Surge Protector 2P 40KA Lightning Arrester Application:

It is mainly applicable for the Direct Current surge protection and over voltage protection in the fields of low voltage DC power supply.
It is applied to provide fine overvoltage protection of electronic equipment whose power is supplied by direct-current power supply.



DC 24v Surge Protector 2P 40KA Lightning Arrester Product detail:



2 Mod TY-40 24
SPD classification according to IEC61643-1 Class II
Operating Voltage                                    Un DC 24V
Max. Continuous Operating Voltage        Uc DC 36V
Nominal discharge current (8/20us)          In 20kA
Max. discharge current (8/20us)           Imax 40kA
Voltage protection level                           Up <300V
Response time                                          tA ≤25ns
Operating temperature range                   Tu -40℃-80℃
Operating state / fault indication green / red
Technology MOV
Format Plug-in modular
Protection Mode +/PE,-/PE
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermal plastic UL94-V0
Degree of protection IP20
Standards compliance    IEC 61643-11 / EN 61643-11 / UL1449 ed.4/GB 18802.1



Dimension:

2P 40KA UL Certified 24v Surge Protector Thermoplastic Material 0

DC 24v Surge Protector 2P 40KA Lightning Arrester Product description:

It is C-level overvoltage protection device, is design according to IEC and GB standard.
Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltage.
It is available in a variety of different power supply voltage and selector corresponding specifications.
Removable assembly, easy to plug and unplug.
It is use for high temperature resistant plastic with excellent tightness, and easy to install wiring.
Guide rail installation, simple operation.
Adopt temperature control circuit technology which has built-in over current breakers and thermal fuse circuit breakers, automatically trip because of deterioration.
High energy MOVs equipped with specific thermal disconnections and related failure indicators.
It has dustproof, anticorrosion and other functions.
These units must be installed in parallel on the dc networks to be protected and provide common and different modes protection.
It is used in a relatively harsh environment staying a long-term stability.
Imax - 40kA/pole (8/20 waveform)
The remote signal port can achieve remote alarm control.

DC 24v Surge Protector 2P 40KA Lightning Arrester Advantage:

• Module designed.
• No follow currents.
• High MOV resistance.
• Color is customizable.
• Logo is customizable.
• 35mm din rail mounted.
• High discharge capacity.
• Package is customizable.
• Mechanical Status Indicator.
• Easy changing of the surge protection module.



Company information:



Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs. Such as ac surge protector, dc surge protection, LED lighting surge arrester, data surge protective device and so on. Our company is located in Yueqing, Zhejiang, China. Convenient transportation, excellent quality and prices and good service attract customers from each place of the world. Our company culture is "sincere and trustworthy, punctuality, high - quality" Welcome every clients!



2P 40KA UL Certified 24v Surge Protector Thermoplastic Material 1



Certificate:



2P 40KA UL Certified 24v Surge Protector Thermoplastic Material 2



FAQ:



Q1. Where is your factory?

  A: Our factory is located in Yueqing city, Zhengjiang Province.



Q2. When can I get the quotation?

  A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the quotation, please tell us in your e-mail so that we will pay more attention to it.



Q3. How can I get a sample to check your quality?

  A: After price confirmation, you can require for samples to check our quality. If you need the sample, we will charge for the sample fee and express fee. Moreover, the sample fee can be refunded after you place the order to us.



Q4. What kind of files do you accept for drawing?

  A: PDF, Core Draw, high resolution Jpg, etc.



Q5. Can you do the design for us?

  A: Yes, we have a professional team having rich experience in design and manufacturing. Just tell us your idea. It does not matter if you do not have someone to complete files. Send us high resolution images, your logo and text and tell us how you would like to arrange them. We will send you finished files for confirmation.
