Thermal Plastic 30kA 48V Modular DC Surge Protection Device Type 2

Product Details:

Place of Origin:	China
Brand Name:	BRITEC
Model Number:	BR-30-48DC

Payment & Shipping Terms:

Minimum Order Quantity:	100 Piece/Pieces
Packaging Details:	EXPORT PACKING
Delivery Time:	Shipped in 15 days after payment
Payment Terms:	L/C, D/A, T/T, Western Union
Supply Ability:	50000 Piece/Pieces Month

Contact Now

Detailed Product Description

Item Name:	DC Surge Protective	Type:	Type 2
Model Number:	BR-30-48DC	Un:	48V DC
Imax:	30kA	Pole Number:	1 Mod
Tu:	-40℃-80℃	Standard:	IEC61643-11
Material:	Thermal Plastic	Place Of Origin:	Zhejiang, China (Mainland)
High Light:	30kA DC Surge Protection Device , 30kA dc surge arrestor , 48V dc power surge protector

48V DC Modular SPD for DC User Surge Arrester High Quality Current Surge Protectors

48V DC Modular SPD Operating Environment:

• Temperature: -40~80centidegree;

• Relative humidity: ≤ 95%;

• Atmospheric Pressure: 70kPa~106kPa

48V DC Modular SPD Product detail:

	BR-30-48DC
SPD classification according to EN61643-11	Type 2
Applicable Power Supply System	DC Power Supply System
Nominal voltage Un	DC 48V
Max. continuous operating voltage Uc	DC 65V
Nominal discharge current (8/20us) In	15kA
Maximum Discharge Current (8/20µs) Imax	30kA
Voltage protection level Up	≤300V
Protection mode(s)	CM
Operating temperature range Tu	-40℃-80℃
Relative Humidity	≤95%RH
Operating state / fault indication	green / red
Cross-section area (Min.)	2.5mm²
Cross-section area (Max.)	16mm²
Protection Mode	"+"-PE, "-"-PE
For mounting on	35mm Din rail
Enclosure material	Thermal plastic UL94-V0
Degree of protection	IP20
Remote Alarm Function	Optional

Product view:
Thermal Plastic 30kA 48V Modular DC Surge Protection Device Type 2 0

48V DC Modular SPD Features:

• With high quality varistor, as well as the automatic break set, operating indicator, invalidation indicator, or degradation indicator and remote interface.

• BR-30-48DC Surge Protection Device was designed and manufactured to comply the PV standard EN50539-11.

• High discharge capacity and low residual voltage.

• Prewired Modular Complete Unit, Consisting of A Base Part and Plug-in Protection Modules.

• Low voltage DC power supply SPD has products with nominal operating voltage of 48V.

• Plug-in Protection Module. Easily Installation and Maintenance.

• Over temperature protection.

• Din Rail Mounting.

• Maximum discharge current: 8/20μ s 30kA.

• IP20, UL94 V0 Technical Data

48V DC Modular SPD Application:

• Used for DC power supply protection system.

• SPD is used to protect all kinds of electrical equipment in the power system from lightning over-voltage, operation over-voltage, power frequency transient over-voltage impact damage to an electrical appliance.

Installation:

This product can only be installed and maintained by qualified professionals. The installation position cannot be touched by hands. Ensure that it is uncharged and check whether the SPD is all right before installation. If there’s damage or the display window is red, the SPD can’t be used anymore; if the window is green, the SPD is normal.

Usage and Maintenance:

1 After failure, the SPD shall be automatically disconnected with the power supply circuit through the internal thermal fuse system, the display window changes to “Red” from “Green”. When the degradation display window is “Red” or there’s a remote alarm signal, the SPD should be changed immediately.

2 The display window of the SPD must be checked after the lightning storm.

Company information:

Wenzhou Britec Electric Co., Ltd. is a professional SPD manufacturer, located in Yueqing, Zhejiang,China, Britec is the specialized manufacturer of surge protection series, such as AC surge protector, DC surge arrester, LED lightning protection and so on. With the advanced facility and technology, we make the first-grade products for our customs. At present, Britec has export and import rights, and our products has been sold to more than 50 countries in the world.

Workshop:

Certificate:

FAQ:

Q1: Are you a trading company or factory?

A: Britec is a factory located in Yueqing, Zhejiang, China. We supply high quality SPD with factory price, and owns export rights.

Q2: What product do you manufacture?

A: We manufacture the AC surge protector, DC surge arrester, LED lightning protection and so on.

Q3: What is the payment term?

A: We accept T/T, Paypal and so on.

Q4: Do you arrange for shipment to buyer’s country?

A: Yes, we will arrange for shipment to any place, but all ocean freight and custom declare fee belongs to buyers side. We accept Ex-works in factory, FOB Ningbo etc.

Q5: What is the delivery time?

A: It takes about 20 working days usually after receipt of your deposit. If we have some stock, we can give you goods in a short time after confirming your payment. Please feel free to contact us.

Q6: What is your warranty?

A: Two years.

Q7: Can I use my LOGO ON THE PRODUCTS?

A: Yes, we accept OEM orders. Please contact us for more details.

Q8: Can I CUSTOMIZE THE PRODUCTS?

A: Yes,you can. Please contact us for the customization products.

Q9: What is the cost of SHIPPING?

A: Shipping cost is based on the following elements: Number of packages; Gross Weight; Package volume; Destination port.
