BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor lightning protector

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor lightning protector

  • BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
  • BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
  • BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
  • BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
  • BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector
Product Details:
Place of Origin: China
Certification: TUV/CB/CE
Model Number: BR-25M 1P
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Brand Name: BRITEC Item Name: T1 Surge Arrester
Place Of Origin: Zhejiang, China Enclosure Material: Thermoplastic, UL94 V‐0
Number Of Positions: 1P Model Numbers: BR-25M 1P
Rated Voltage: AC 275V EN Type: Type 1
Color: White
High Light:

T1 single phase SPD

,

Thermoplastic single phase SPD

,

Thermoplastic 25ka spd

T1 surge arrester Class I+II 25kA single phase voltage protection device



T1 surge arrester Features:



The BTITEC surge arrester series has been specifically designed to offer surge protection for electrical equipment. Surge arresters are installed at the front end of a system for the purpose of diverting harmful overvoltage transients caused by external (lightning) and/or internal (switching) events to ground safely. Also known as Surge Protection Device (SPD), or Transient Voltage Surge Suppressor (TVSS),BRITEC surge arrestors protect against electrical transients resulting from lightning strikes that find their way onto electrical conductors.


Protection class: Type 1,Class I

Pole number:1P,2P,3P,4P,1+1,3+1 optional

Widely used for protecting the buildings to avoid national defense

The combination lightning current and surge arrestors meet the type 1+2 requirement class according to IEC 61643-1.



T1 surge arrester Technology characteristic:

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 0



  BR-25M 1P
Max. continuous operating a.c. voltage                              Uc 275V
Lightning impulse current (10/350us)                               Iimp 25kA
Nominal discharge current (8/20us)                                     In 25kA
Maximum discharge current (8/20us)                              Imax 100kA
Voltage protection level                                                      Up ≤1.3kV
Response time                                                                     tA ≤25ns
Max. backup fuse 315A
Operating temperature range                                              Tu -40℃—80℃
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermoplastic UL94-V0
Test standards             IEC 61643-11, EN 61643-11


T1 surge arrester Dimension:



BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 1



T1 surge arrester Application:


Application: Grid Power, AC Power Circuit, AC Distribution Box, LT Electrical Panel

AC SPD uses for AC Power or Grid Power to protect against transient ac voltage.


T1 surge arrester Certificate:


CB, CE, TUV,RoHS Certificate:


BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 2

Company information:

Wenzhou Britec Electric Co., Ltd. established in the year of 2003 and located in Yueqing, Zhejiang, China. We are a comprehensive international manufacturer & trading company for SPDs. Most of our products are sold to Germany, United Kingdom, Italy, Spain, France, Hungary, Brazil, Argentina, South Korea, Hongkong, Singapore, Malaysia, Thailand, Indonesia, other countries and regions. Our business principle is to satisfy our customers with honest, surefooted and considerate service.

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 3

Production line:

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 4
BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 5

Laboratory equipment:

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 6

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 7

Shipping:

BR-25M 1P T1 Class I+II 25kA Single Phase SPD surge Arrestor  lightning protector 8

FAQ:

Q1: What is the MOQ?
A1: 1pcs.

Q2: Is OEM/ODM available?
A2: Yes, it is! Our products can be Customized. We have design and engineer teams, we can
      customize products according to customers’ drawing or requirements.

Q3: Can we put/show our own Logo on your products?
A3: Yes.

Q4: What is the Terms of Payment?
A4: T/T, PAYPAL, L/C etc.

Q5: How is the delivery time?
A5: It depends your order quantity and it normally takes 7-20 days.
