|Place of Origin:||China|
|Minimum Order Quantity:||200 piece / pieces|
|Packaging Details:||EXPORT PACKING|
|Delivery Time:||15-30 days after payment|
|Supply Ability:||50000 pieces per month|
|Produc Name:||DC Surge Protective Device||Test Standards:||EN61643-11 / EN50539-11|
|Nominal Discharge Current:||20kA||Max. Discharge Current:||40kA|
|Mounting Support:||35mm Din Rail||Application:||DC Power System|
PV solar surge arrester,
2P solar lightning arrester,
lightning pv surge arrester
Solar System Surge Arrester 2P 800V 40ka Power Lightning Protector 2 Poles House Din Rail
Solar System Surge Arrester 2P 800V 40ka Power Lightning Protector Product Details:
|SPD classification according to EN61643-11||Type 2|
|SPD classification according to EN50539-11||Class II|
|Max. continuous operating dc voltage Ucpv||800V|
|Nominal discharge current (8/20us) In||20kA|
|Max. discharge current (8/20us) Imax||40kA|
|Voltage protection level Up||≤3.0kV|
|Response time tA||≤25ns|
|Operating temperature range Tu||-40℃-80℃|
|Operating state / fault indication||green / red|
|Cross-section area (Min.)||4mm2|
|Cross-section area (Max.)||35mm2|
|For mounting on||35mm Din rail|
|Enclosure material||Thermal plastic UL94-V0|
|Degree of protection||IP20|
Solar System Surge Arrester 2P 800V 40ka Power Lightning Protector Application:
• Apply to the Photovoltaic power grid-connection system.
• It is widely used in the DC power lightning protection of solar power systems, mobile communication base stations, microwave communications bureau, telecommunications room, plant, civil aviation, finance, securities and other system.
Why Choose Us?
1: Over 17 years’ experience in production and processing.
2: Faster product innovation, production specialization, timely delivery.
3: Strict quality inspection procedure.
Why need pv surge arrester?
Most of the solar modules are very regularly exposed to lightnings and overvoltages, where lighting occurrences are frequent, unprotected PV systems can suffer repeated and significant damage to key components. And these systems represent a significant investment cost, system downtime and the loss of revenue. PV modules, DC cabling, inverters, AC cabling, as well as monitoring systems must all be protecting as part of a in all-inclusive effort to mitigate the damaging effects of lightning and surges. The use of adapted surge protections is then highly recommended.
Wenzhou Britec Electric Co., Ltd. is a professional SPD manufacturer, located in Yueqing, Zhejiang, China, Britec is the specialized manufacturer of low voltage surge protection device. With the advanced facility and technology, we make the first-grade products for our customs. At present, Britec has export and import rights, and our products has been sold to more than 50 countries in the world.
Q1: Are you a trading company or factory?
A: Britec is a factory located in Yueqing, Zhejiang, China. We supply high quality SPD with factory price, and owns export and import rights.
Q2: What product do you manufacture?
A: We manufacture all kinds of SPDs, including AC surge protector, DC surge protection device, data surge protective device, LED lightning arrester and so on
Q3: What is the payment term?
A: We accept T/T, Paypal, L/C and so on.
Q4: Do you arrange for shipment to buyer’s country?
A: Yes, we will arrange for shipment to any place, but all ocean freight and custom declare fee belongs to buyers side. We accept Ex-works in factory, FOB Ningbo, etc.
Q5: What is the delivery time?
A: It takes about 15~30 working days usually after receipt of your deposit. If we have some stock, we can give you goods in a short time after confirming your payment. Please feel free to contact us.
Q6: What is your warranty?
A: Two years.
Q7: Can I use my LOGO ON THE PRODUCTS?
A: Yes, we accept OEM orders. Please contact us for more details.
Q8: Can I CUSTOMIZE THE PRODUCTS?
A: Yes, you can. Please contact us for the customization products.
Q9: What is the cost of SHIPPING?
A: Shipping cost is based on the following elements: Number of packages; Gross Weight; Package volume; Destination port
