Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System

Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System

  • Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System
  • Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System
Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: BR12-20
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Place Of Origin: Zhejiang, China (Mainland) Imax: 20kA
Model Number: BR12-20 Up: ≤320V
Material: Flame Retardant Materials Uc: 20V DC
Pole Number: 2P Protect Mode: "+"-PE/"-"-PE
MOQ: 100pcs Keyword: DC Surge Protector
High Light:

12v dc surge protector

,

dc surge suppressor

Factory 2P 12V DC Power Supply Surge Protector for Solar System



Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector Characteristic:


• PV power surge protector.
• Plugged modules.
• 35MM Din rail mounting.
• Operation state indicator.
• Remote signal mechanism: optional.
• Mode of Protection: (DC+) – PE, (DC-) – PE, (DC+) – (DC-).
• Tested and certified as Type 2 according to regulations EN 61643-11.
• The MOV are equipped with internal thermal disconnections in order to provide safe end of life.
• These devices are based on high energy varistors (MOV) matched with the DC operating voltage from 12V to 48V DC.
• It reacts to voltage impulses in a few nanoseconds, thus achieving a very low residual voltage, protecting even highly sensitive equipment.



Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector Product detail:



2 Mod BR12-20
SPD classification according to IEC61643-1 Class II
Operating Voltage                                                        Un 12V DC
Max. Continuous Operating Voltage                            Uc 20V DC
Nominal discharge current (8/20us)                              In 10kA
Max. discharge current (8/20us)                               Imax 20kA
Voltage Protection Level                                              Up ≤320V
Response time                                                              tA ≤25ns
Leakage current ≤20µA
Operating temperature range                                       Tu -40℃-80℃
Operating state / fault indication green / red
Protection Mode +/PE,-/PE
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material                   Thermal plastic UL94-V0
Degree of protection IP20
Remote Signalling Optional



Dimension:



Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System 0


Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector Application:

• For use in photovoltaic systems.
• Mainly used for DC supply lines.
• For installation in the DC circuits of solar photovoltaic systems, string box, inverter.
• Protect against lightning surge voltages in solar system (photovoltaic power supply system).

Advantage:

• Retardant materials.
• Low protection level.
• Low residual voltage.
• Very fast response.
• Easy and fast maintenance.
• Customized logo & label printing.

Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector Installation:

• These units must be installed in parallel on the dc networks to be protected.
• It is essential to connect correctly the input and output terminals. Otherwise the SPD components will not work properly.



Why us:



Wenzhou Britec Electric Co.,Ltd. specializes in R&D, production, sales SPDs. Products sold at home and abroad, well received by customers. Our mission is to produce highly cost-effective surge protection products for our customers. The company is determined to stick to a principle of "advanced technology and best quality" and provide the customers with perfect lightning arrester products. Britec has and will put customers first.



Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System 1



Certifications:



Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System 2



FAQ:


Q1: Are you a manufacturer or trading company?
A1: We are a manufacturer, a company in the lightning protector field.



Q2: What products can you supply?
A2: Our products include AC power surge arrester, DC surge protective, data surge protector, LED lightning protection etc.



Q3: What certification do you have?
A3: TUV/CE/CB etc.



Q4: Can I see the sample first before I place the real order?
A4: Yes, of course.



Q5: What's your delivery time?
A5: It depends on the quantity you need.
