BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection

BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection

  • BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection
  • BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection
BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection
Product Details:
Place of Origin: China
Brand Name: BRITEC
Certification: TUV/CB/CE/ROHS/ISO9001
Model Number: BRPI-2L-24
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: carton
Delivery Time: 15 days after receipt of deposit
Payment Terms: TT
Supply Ability: 1000000 per month
Contact Now
Detailed Product Description
Degree Of Protection: IP20 Product Name: Data Surge Protector
Operating Temperature Range: -40℃…+80℃ Enclosure Material: Thermoplastic UL94-V0
Response Time: 1ns Weight: 0.5kg
Nominal Current: 0.5A Frequency: 50/60Hz
Highlight:

BRPI-2L-24 Data Surge Protector

,

0.5A Digital Internet Surge Protection Device

,

60Hz Digital Internet Surge Protector

Product Description:

Data Surge Protector is the perfect solution for data signal protection. It provides a surge protection network to protect against signal surges up to 24V, with an IP20 degree of protection and an insertion loss of ≤0.3dB. This lightweight device, weighing only 0.5kg, is designed with a fast response time of 1ns. It is an ideal signal surge arrestor for various data systems, providing reliable protection against surges.



Features:

  • Data Surge Protector
  • Norminal voltage: 24V
  • Response Time: 1ns
  • Weight: 0.5kg
  • Insertion Loss: ≤0.3dB
  • Operating temperature range: -40℃…+80℃
  • Signal Surge Arrestor
  • Data Signal Protector
  • Signal Protector



BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection 0



Technical Parameters:



Specification



BRPI-2L-6

BRPI-2L-12

BRPI-2L-24

BRPI-2L-48

BRPI-2L-60

BRPI-2L-180

Test standards



IEC 61643-21

Norminal voltage

Un

6V

12V

24V

48V

60V

180V

Max. continuous operating d.c. voltage

Uc

8V

15V

29V

56V

70V

180V

Max. continuous operating a.c. voltage

Uc

5V

11V

20V

40V

49V

130V

Nominal current

IL

0.5A

0.5A

0.5A

0.5A

0.5A

0.5A

C2 Norminal discharge current (8/20μs) per line

In

5kA

5kA

5kA

5kA

5kA

5kA

Voltage protection level [line-line]

Up

≤30V

≤40V

≤60V

≤100V

≤130V

≤320V

Voltage protection level [line-PG]

Up

≤600V

≤600V

≤600V

≤600V

≤600V

≤600V

Response time [line-line]

tA

≤1ns

≤1ns

≤1ns

≤1ns

≤1ns

≤1ns

Response time [line-PG]

tA

≤100ns

≤100ns

≤100ns

≤100ns

≤100ns

≤100ns

Operating temperature range

Tu

-40…+80

Connection input/output



Terminal Block

Bandwidth



10Mbps

10Mbps

10Mbps

10Mbps

10Mbps

10Mbps

Insertion Loss



≤0.3dB

≤0.3dB

≤0.3dB

≤0.3dB

≤0.3dB

≤0.3dB

Enclosure material



Thermoplastic UL94-V0

Degree of protection



IP20

IP20

IP20

IP20

IP20

IP20

Order Code



D9100

D9101

D9102

D9103

D9104

D9105

ac surge protection Applications:

Data Surge Protector is a brand name of BRITEC and the model number is BRPI-2L-24. It is certified by TUV/CB/CE/ROHS/ISO9001. The minimum order quantity is 1PCS and it is delivered in a carton package. The delivery time is 15 days after receipt of deposit and payment terms are TT. The supply ability is 1000000 per month. It has an insertion loss of ≤0.3dB, an operating temperature range of -40℃…+80℃, an enclosure material of thermoplastic UL94-V0 and a response time of 1ns. It is the perfect surge protection network and signal surge arrestor to ensure the safety of any network.

The Data Surge Protector is perfect for any network and it is a must-have for any IT professional. It is designed to protect networks and servers from surges and other electrical hazards. It is ideal for protecting sensitive equipment, such as routers, servers, and workstations. It is also great for protecting critical data and other valuable assets. It can provide reliable surge protection and long-term protection against any potential damage.

The Data Surge Protector can be used in homes, offices, and other commercial settings. It is also great for industrial, medical, and military applications. It is a reliable solution for providing surge protection for networks in any environment. It is also an excellent choice for protecting data and other valuable assets. It is a must-have for any network and provides peace of mind knowing that all of your data and equipment is safe and secure.



Customization:

Data Surge Protector: BRITEC BRPI-2L-24

This data surge protector is designed for wall mounting and is a reliable solution for surge protection network of data signals. With certification from TUV/CB/CE/ROHS/ISO9001, it is of high quality and safety. It has a minimum order quantity of 1PCS and is packaged in a carton. Delivery time is 15 days after receipt of deposit with payment terms of TT. It has a supply ability of 1000000 per month.

Product Features:
  • Degree of protection: IP20
  • Frequency: 50/60Hz
  • Insertion Loss: ≤0.3dB
  • Operating temperature range: -40℃…+80℃
  • Response Time: 1ns

This data surge protector is ideal for use in surge protection network of data signal. It provides reliable protection for your data signals and is the perfect solution for all your data signal and surge protection needs.



Support and Services:

Data Surge Protector Technical Support and Service

At Data Surge Protector, we understand the importance of having reliable technical support and service. We are committed to providing our customers with the highest level of support and service possible. Our team of experienced and knowledgeable technicians are ready to answer any questions you may have and provide assistance whenever needed.



BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection 1



BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection 2



BRPI-2L-24 Data Surge Protector Protection Device Digital Internet 60Hz ac surge protection 3
