Network Rj45 Surge Protector Gigabit Ethernet Signal Lan spd network

Product Details:

Place of Origin:	China
Brand Name:	BRITEC
Certification:	TUV/CB/CE/ROHS/ISO9001
Model Number:	BRRJ45H-8L

Payment & Shipping Terms:

Minimum Order Quantity:	10 Piece/Pieces
Packaging Details:	EXPORT PACKING
Delivery Time:	Shipped in 15-20 days after payment
Payment Terms:	T/T
Supply Ability:	50000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Type:	Rj45 Power Surge Protector	Connection:	RJ45 Socket
Protection Class:	IP20	Material:	Shielded Aluminum Alloy
Vs:	1000 Mbps	Un:	5v
Nominal Discharge Current:	5kA	Insertion Loss:	≤0.3dB
Compatible Devices:	PoI , Personal Computer , LAN , Router
Highlight:	Gigabit Ethernet Power Surge Protector , Rj45 Power Surge Protector , Interface Network Power Surge Protector

ethernet surge protection devices RJ45 Arrester Ethernet Networking Surge Protector

Color:black and white

Imax(Maximum discharge current):10KA
Un=5v,Uc=6v
Warranty:2 year
Vs:1000Mbps
interface:RJ45

Product name:rj45 surge protector
Place of Origin:CN;ZHE

Ethernet Networking Surge Protector Product Details:

	BRRJ45H-8L
Test standards	IEC61643-21
Nominal voltage Un	5V
Max.continuous operating d.c.voltage Uc	6V
Max.continuous operating a.c.voltage Uc	4V
Nominal current IL	0.5A
C2 Nominal discharge current (8/20us) per line In	5kA
Voltage protection level [line-line] Up	≤30V
Voltage protection level [line-PG] Up	≤500V
Response time [line-line] tA	≤1ns
Response time [line-PG] tA	≤100ns
Operating temperature range Tu	-40℃…+80℃
Connection (input/output)	RJ45 socket 8 line
Data rates	1000 Mbps
Insertion Loss	≤0.3dB
Enclosure material	aluminium alloy
Degree of protection	IP20

Application:

to prevent indirect lightning or direct lightning impact and network over-voltage damage to signal equipment.

Company information:

Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs. Such as ac surge protector, dc surge protection, LED lighting surge arrester, data surge protective device and so on. Our company is located in Yueqing, Zhejiang, China. Britec Electric Wenzhou Co., Ltd. was established in 2003.We are providing quality products, competitive price, prompt delivery and excellent service, and looking forward to even greater cooperation with overseas trade based on mutual benefits.

Certificate:

We got CB, CE, TUV,RoHS Certificate:

Payment & Shipping:

FAQ:

Q1:Are you a lightning surge protectors factory or lightning surge protectors trading company?
A1: We are lightning surge protectors manufacturer.

Q2: Warranty and return:
A2:1. Warranty 5 years
2. lightning surge protectors products and accessories have been tested 3 times before ship out.
3. We own the best after-sale service team, if any problem happens, our team will do our best to solve it for you.

Q3: How can I get some lightning surge protectors samples?
A3: We are honored to offer you lightning surge protectors samples, pls contact our staff and leave detailed contact information.

Q4: Is sample available and free?
A4: Sample is avaible, but the sample cost should be pay by you.The cost of sample will be refund after further order.

Q5:Do you accept customized order?
A5:Yes, we do.

Q6: What's the delievery time?
A6:It usually takes 7-15days after confirming payment, but specific time should be based on the order quantity.
