120KA Type 2 Power Overvoltage Protection Surge Arrester AC Lightning

120KA Type 2 Power Overvoltage Protection Surge Arrester AC Lightning

  • 120KA Type 2 Power Overvoltage Protection Surge Arrester AC Lightning
  • 120KA Type 2 Power Overvoltage Protection Surge Arrester AC Lightning
120KA Type 2 Power Overvoltage Protection Surge Arrester AC Lightning
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: TY1-120 4P
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Warranty: 2 Years Item Name: Surge Protection Device
Color: White Type: Ac Surge Protector
Material: Plastic Pole Number: 4P
UC: 385V Imax: 120kA
Degree Of Protection: IP20 Tu: -40℃-80℃
High Light:

AC Lightning Surge Arrester Protection

,

120KA Surge Arrester

,

Type 2 Power Surge Overvoltage Protection

120KA Surge Arrester Type 2 Power Overvoltage Protection AC Lightning Protection



120KA Surge Arrester Type 2 Power Overvoltage Protection Product description:

Britec Surge Protection Device (SPD) (also known as power Surge protector, overvoltage protector), its design according to GB18802.1, IEC61643-1 standards
Type 2 Class II surge arrester.
Applicable to lightning strike electromagnetic pulse (LEMP) protection for TN-S power supply line systems with ac 380V (50Hz/60Hz) and below.



120KA Surge Arrester Type 2 Power Overvoltage Protection Technology characteristic:



Specification TY1-120 4P
Item name Surge Arrester
SPD dassification according to EN61643-11 Type 2
SPD dassification according to IEC61643-11 Class II
Max continuous 0perating a.c. voltage         Uc 385V
Max. discharge current (8/20µs)                Imax 120kA
Norminal discharge current (8/20µs)            In 60kA
Voltage protection level                               Up ≤2.5kV
Response time                                             tA ≤25ns
For mounting on 35mm Din rail
Degree of protection IP20
Max. backup fuse 315A gG
Operating temperature range                      Tu -40℃—80℃
Cross-section area (Min.) 6mm2
Cross-section area (Max.) 35mm2
Enclosure material Thermal plastic UL94-V0



120KA Surge Arrester Type 2 Power Overvoltage Protection Features:

Optional remote signal terminal alarm function, easy to remote alarm monitoring
Up to 120KA(8/20μs) lightning current impact
Fast reaction speed, action response time less than 25ns
Flame retardant housing design, easy to install on 35mm electrical guide rail
Built-in thermal release failure and release device, so that the protector can be automatically disconnected due to overheating, breakdown failure



Product standard:

1) EN60950:Safety of information technology equipment, including electrical business equipment
2) GB18802.1 low-voltage distribution system SP: performance demand and test method;
3) IEC61643-1:1998 Surge Protective devices connected to Low-voltage power
4) YD/T 1235.1 Communication Station low-voltage power system SPD technical requirement;
5) YD/T 1235.2 Communication Station low-voltage power system SPD test method;
6) Distribution system.Part1:Performance requirements and testing methods
