DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window

DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window

  • DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window
  • DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window
DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: TY-40 220
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Type: DC Power Surge Protector 220VDC Class: Class II
Connection Mode: +/-/PE Item Name: DC Surge Protective Device
Max. Continuous Voltage: DC 220V Max. Discharge Current: 40kA
Voltage Protection: ≤900V Response Time: ≤25ns
Protection Level: IP20 Application: DC Power System
High Light:

IP20 Lightning Surge Protector

,

40KA SPD Lightning Surge Protector

,

40KA 220v surge protector

Dc 220V Surge Protector 40KA SPD Lightning Protection Device SPD Surge Protection



Dc 220V Surge Protector 40KA SPD Lightning Protection Device Features:

Fast response time
Pluggable module, consisting of a base and pluggable protection module
Double tripping device, safe and reliable
With failure display window, remote signaling can be configured
35mm din rail mounting, installation and maintenance is easy and convenient
We can provide a variety of models for different DC power supplies



Dc 220V Surge Protector 40KA SPD Lightning Protection Device Product detail:



2 Mod TY-40 220
SPD classification according to IEC61643-1 Class II
Max. Continuous Operating Voltage        Uc DC 220V
Nominal discharge current (8/20us)          In 20kA
Max. discharge current (8/20us)           Imax 40kA
Voltage protection level                           Up <900V
Response time                                          tA ≤25ns
Operating temperature range                   Tu -40℃-80℃
Operating state / fault indication green / red
Technology MOV
Format Plug-in modular
Protection Mode +/PE,-/PE
Cross-section area (Min.) 4mm2
Cross-section area (Max.) 35mm2
For mounting on 35mm Din rail
Enclosure material Thermal plastic UL94-V0
Degree of protection IP20
Standards compliance    IEC 61643-11 / EN 61643-11 / UL1449 ed.4/GB 18802.1


Dimension:
DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window 0

Dc 220V Surge Protector 40KA SPD Lightning Protection Device Application:

Suitable for lightning protection of dc power distribution panel, DC distribution box and DC power supply equipment.
Used to prevent damage caused by lightning overvoltage and transient overvoltage to secondary DC power supply system and electrical equipment.

Dc 220V Surge Protector 40KA SPD Lightning Protection Device Operating environment:

Operating temperature: -40℃~+80℃
Relative humidity:5%-95%
Atmosphere pressure:70kPa~106kPa


Company information:

Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs. Such as ac surge protector, dc surge protection, LED lighting surge arrester, data surge protective device and so on. Our company is located in Yueqing, Zhejiang, China. Convenient transportation, excellent quality and prices and good service attract customers from each place of the world. Our company culture is "sincere and trustworthy, punctuality, high - quality" Welcome every clients!

DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window 1

Certificate:

DC 220V 40KA SPD Lightning Surge Protector With Failure Display Window 2

FAQ:

Q1. Where is your factory?
  A: Our factory is located in Yueqing city, Zhengjiang Province.

Q2. When can I get the quotation?
  A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the quotation, please tell us in your e-mail so that we will pay more attention to it.

Q3. How can I get a sample to check your quality?
  A: After price confirmation, you can require for samples to check our quality. If you need the sample, we will charge for the sample fee and express fee. Moreover, the sample fee can be refunded after you place the order to us.

Q4. What kind of files do you accept for drawing?
  A: PDF, Core Draw, high resolution Jpg, etc.

Q5. Can you do the design for us?
  A: Yes, we have a professional team having rich experience in design and manufacturing. Just tell us your idea. It does not matter if you do not have someone to complete files. Send us high resolution images, your logo and text and tell us how you would like to arrange them. We will send you finished files for confirmation.
