Home ProductsType 2 Surge Protection Device

30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P

30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P

  • 30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P
  • 30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P
30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P
Product Details:
Place of Origin: China
Brand Name: BRITEC
Model Number: BR4-30 2P
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: USD 15-40 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: T/T
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Item Name: Surge Protector Type: Ac Surge Protection
Material: Plastic Pole Number: 2P
Uc: 275V In: 15kA
Imax: 30kA Certificate: CB/CE/ROHS/ISO9001
Tu: -40℃-80℃ Application: Surge Arrester Is Suitable For LEPM Zone
High Light:

2 pole surge protector

,

type 2 surge protector

30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P



30kA 275V Single Phase 2P Type 2 Class II Surge Arresters Features:



• Protecting low-voltage consumers' installations against indirect lightning discharges

• High performance varistor with thermal disconnection tripping device

• Plug-in module/base design facilitate replacement of a failed module without the need to remove system wiring etc.

• Protection class: Type 2, Class II

• Pole number:1P,2P,3P,4P,1+1,3+1

• Surge protectors are used to guard sensitive equipments from voltage spike



30kA 275V Single Phase 2P Type 2 Class II Surge Arresters Product characteristics:



Specification BR4-30 2P BR4-30 4P
Item name  Surge Arrester Surge Arrester
SPD classification according to EN61643-11 Type 2 Type 2
SPD classification according to IEC61643-11 Class II Class II
Max continuous 0perating a.c. voltage            Uc 275V 275V
Norminal discharge current (8/20µs)                In 15kA 15kA
Max. discharge current (8/20μs)                  Imax 30kA 30kA
Operating temperature range                          Tu -40℃—80℃ -40℃—80℃
Voltage protection level                                   Up ≤1.5kV ≤1.5kV

Width of one pole

18mm

18mm

Remote contacts

Available

Available

For mounting on 35mm Din rail

35mm Din rail

Degree of protection IP20 IP20
Cross-section area (Min.) 2.5mm²
Cross-section area (Max.) 16mm²
Enclosure material Thermal plastic UL94-V0



Workshop:


Britec owns advanced test equipments and product line, perfect management, professional technical personnel and well-trained workers. Britec team keep developing newest product for our customer, that is why technical level of our products can be reached to the leading level, we also can help customer OEM/ODM.


30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P 0


Company Information:

Wenzhou Britec Electric Co., Ltd. was established in 2003, is a professional surge protective devices (SPD) manufacture with many years experiences.We are providing quality products, competitive price, prompt delivery and excellent service, and looking forward to even greater cooperation with overseas trade based on mutual benefits.

30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P 1

Exhibition:


Britec have strong sales team, our surge protection device are sold to many countries around the world. Europe and Asia are our main market. We would like to cooperate with global customers and help you success in your market.


30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P 2


Certifications:


Britec offer full range of SPD products which has CE, RoHS,TUV, SEMKO, CB certification.The company implements ISO9001 quality mangement system.


30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P 3


Product Uses:


Britec have developed a wide range of products mainly covering requirements in the area of low voltage lightning protection, such as SPD for power system,PV system and data , etc. All these products have been widely applied in electronic system, computer network and security system, protection for power industry, petroleum chemical industry and national defense industry.


30kA 275V Single Phase 2P Type 2 Class II Surge Arresters BR4-30 2P 4



FAQ:



Q1: Are you a lightning surge protectors factory or lightning arrester trading company?

A2: We are surge protection device manufacturer.



Q2: Is sample available and free?

A2: Sample is avaible, but the sample cost should be pay by you. The cost of sample will be refund after further order.



Q3: How can I get some surge arrester samples?

A3: We are honored to offer you SPD samples, please contact our staff and leave detailed contact information, we promise to keep your information confidential.



Q4: Do you accept customized order?

A4: Yes, we do.



Q5: What's the delievery time?

A5: It usually takes 20days after confirming payment, but specific time should be based on the order quantity.
