10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life

10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life

    • 10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life
    • 10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life
  • 10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life

    Product Details:

    Place of Origin: China
    Brand Name: BRITEC
    Certification: CE
    Model Number: BR18-32 1P

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 Piece/Pieces
    Packaging Details: EXPORT PACKING
    Delivery Time: Shipped in 15 days after payment
    Payment Terms: L/C, D/A, T/T, Western Union
    Supply Ability: 50000 Piece/Pieces Month
    Contact Now
    Detailed Product Description
    Item Name: Midget Fuse Material: Plastic
    Pole Number: 1P Brand Name: Britec
    Protection: IP20 Certificate: CE
    Tu: -40℃-80℃ UC: 690V
    Rated Currents: 32A Model Number: BR18-32N
    Usage: Low Voltage Breaking Capac: High

    690v 32a one phase cartridge for Midget fuse CE BR18-32 1P



    Features:



    • Rated voltage:AC 500V.

    • Rated current:32A.

    • Poles number:1P, 1+N, 2P, 3P, 3+N.

    • The plastic body is made of Thermal plastic UL94-V0.

    • BR18-32 series spark gap power surge protector is designed and manufactured according to IEC

      60269 standards.

    • Neon light and resistance comprise the fuse base's fuselink fuse signal device (code “X”).

    • RT18 series holder can be used in combination with BR18-32, BR18-63, “gG” fuse links, “gG” is the

      general-purpose fuse link with full-range breaking capacity.

    • Support parts of this series with a fuse withstand thermal current and expected impact of current sprint

      to 100KA dynamic thermal stability capabilities.

    • This product can be mounted on a standard 35mm DIN rail mounting.



    Technology characteristic:



    Size Fuse Link Size No. of poles Order No.     Weight(g)
    Rated current 32A
        BR18-32     10X38 1 BR1832 1P 59
    1+N BR1832 1PN 118
    2 BR1832 2P 118
    3 BR1832 3P 177
    3+N       BR1832 3PN       236



    Dimension:

    10x38 32A Safety Single Pole Circuit Breaker Switch Gg Fuse Links Long Service Life

    Size Class rating(A) Dimension
    A B C D E
          BR18-32       32         78                 78                 18                 60                 80



    Application:



    • BR18-32 series cylindrical cap fuse applies to power distribution system with AC 50Hz, rated voltage of

      500V, and rated current of 32A, to protect overload and short circuit (it is not recommended but RT16

      fuse in capacitor box).

    • It can be applied to single-phase or three-phase power supply in the class I lightning protection of

      equipment and power system with high lightning risk.

    • Can be widely used in various wiring applications, such as: switchboard, control panel, transformer,

      mechanical equipment, continuous line system, generator set, refrigeration air conditioning, battery

      pack, lighting equipment, ships and aircraft, etc.



    Advantage:



    • Competitive price.

    • Fast delivery.

    • It has high safety factor and long service life.

    • The product has high lightning current discharge capacity, up to 5kA (10 350μS), which can prevent

      direct lightning strikes and other surge current.

    • Modular design can be based on customer needs and combined with the side cover assembly into any

      electrical circuit number.
