Name: 2P 800V 40KA Solar Dc SPD PV Surge Protector High Energy Varistor
Brand: BRITEC
SKU: BRPV2-800

2P 800V 40KA Solar Dc SPD PV Surge Protector High Energy Varistor

Product Details:

Place of Origin:	China
Brand Name:	BRITEC
Certification:	CE
Model Number:	BRPV2-800

Payment & Shipping Terms:

Minimum Order Quantity:	200 piece / pieces
Packaging Details:	EXPORT PACKING
Delivery Time:	15-30 days after payment
Payment Terms:	T/T
Supply Ability:	50000 pieces per month

Contact Now

Detailed Product Description

Test Standards:	EN61643-11 / EN50539-11	Class:	Class II
Ucpv:	800V	In:	20kA
Imax:	40kA	Up:	≤3.0kV
Pole Number:	2P	Material:	Thermal Plastic UL94-V0
Mounting Support:	35mm Din Rail	Application:	DC Power System
High Light:	40KA pv surge protector , SPD pv surge protector , Class II solar dc spd

Solar System 2P DC 800V 20KA~40KA Low-voltage Arrester House Din Rail 2 Poles Surge Protector

Solar System 2P DC 800V 20KA~40KA Low-voltage Arrester Description:

• Rated voltage 800V DC, maximum discharge current 40KA, High Energy Varistor, high effective for lightning protection.

• Surge protection device (SPD) is an indispensable device for lightning protection of electronic equipment.

• BRPV Surge Protection Device was designed and manufactured to complying the PV standard EN50539-11.

Solar System 2P DC 800V 20KA~40KA Low-voltage Arrester Product Details:

	BRPV2 800
SPD classification according to EN61643-11	Type 2
SPD classification according to EN50539-11	Class II
Max. continuous operating dc voltage Ucpv	800V
Nominal discharge current (8/20us) In	20kA
Max. discharge current (8/20us) Imax	40kA
Voltage protection level Up	≤3.0kV
Response time tA	≤25ns
Operating temperature range Tu	-40℃-80℃
Operating state / fault indication	green / red
Cross-section area (Min.)	4mm²
Cross-section area (Max.)	35mm²
For mounting on	35mm Din rail
Enclosure material	Thermal plastic UL94-V0
Degree of protection	IP20

Technology characteristic:

Solar System 2P DC 800V 20KA~40KA Low-voltage Arrester Application:

• It widely used in PV DC combiner box, inverter, controller and PV DC cabinet.

• Protect against lightning surge voltages in solar system.

• Suitable For Use in All Photovoltaic Systems.

Why Choose Us?

• 1: Over 17 years’ experience in production and processing.

• 2: Faster product innovation, production specialization, timely delivery.

• 3: Strict quality inspection procedure.

Why need pv surge arrester?

Most of the solar modules are very regularly exposed to lightnings and overvoltages, where lighting occurrences are frequent, unprotected PV systems can suffer repeated and significant damage to key components. And these systems represent a significant investment cost, system downtime and the loss of revenue. PV modules, DC cabling, inverters, AC cabling, as well as monitoring systems must all be protecting as part of a in all-inclusive effort to mitigate the damaging effects of lightning and surges. The use of adapted surge protections is then highly recommended.

Certifications:

Company profile:

Wenzhou Britec Electric Co., Ltd. is a professional SPD manufacturer, located in Yueqing, Zhejiang, China, Britec is the specialized manufacturer of low voltage surge protection device. With the advanced facility and technology, we make the first-grade products for our customs. At present, Britec has export and import rights, and our products has been sold to more than 50 countries in the world.

Shipping:

FAQ:

Q1: Are you a trading company or factory?

A: Britec is a factory located in Yueqing, Zhejiang, China. We supply high quality SPD with factory price, and owns export and import rights.

Q2: What product do you manufacture?

A: We manufacture all kinds of SPDs, including AC surge protector, DC surge protection device, data surge protective device, LED lightning arrester and so on

Q3: What is the payment term?

A: We accept T/T, Paypal, L/C and so on.

Q4: Do you arrange for shipment to buyer’s country?

A: Yes, we will arrange for shipment to any place, but all ocean freight and custom declare fee belongs to buyers side. We accept Ex-works in factory, FOB Ningbo, etc.

Q5: What is the delivery time?

A: It takes about 15~30 working days usually after receipt of your deposit. If we have some stock, we can give you goods in a short time after confirming your payment. Please feel free to contact us.

Q6: What is your warranty?

A: Two years.

Q7: Can I use my LOGO ON THE PRODUCTS?

A: Yes, we accept OEM orders. Please contact us for more details.

Q8: Can I CUSTOMIZE THE PRODUCTS?

A: Yes, you can. Please contact us for the customization products.

Q9: What is the cost of SHIPPING?

A: Shipping cost is based on the following elements: Number of packages; Gross Weight; Package volume; Destination port
