Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System

Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System

    • Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System
    • Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System
  • Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System

    Product Details:

    Place of Origin: China
    Brand Name: BRITEC
    Model Number: BR12-20

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 Piece/Pieces
    Packaging Details: EXPORT PACKING
    Delivery Time: Shipped in 15 days after payment
    Payment Terms: L/C, D/A, T/T, Western Union
    Supply Ability: 50000 Piece/Pieces Month
    Contact Now
    Detailed Product Description
    Place Of Origin: Zhejiang, China (Mainland) Imax: 20kA
    Model Number: BR12-20 Up: ≤320V
    Material: Flame Retardant Materials Uc: 20V DC
    Pole Number: 2P Protect Mode: "+"-PE/"-"-PE
    MOQ: 100pcs Keyword: DC Surge Protector

    Factory 2P 12V DC Power Supply Surge Protector for Solar System



    Characteristic:


    • PV power surge protector.
    • Plugged modules.
    • 35MM Din rail mounting.
    • Operation state indicator.
    • Remote signal mechanism: optional.
    • Mode of Protection: (DC+) – PE, (DC-) – PE, (DC+) – (DC-).
    • Tested and certified as Type 2 according to regulations EN 61643-11.
    • The MOV are equipped with internal thermal disconnections in order to provide safe end of life.
    • These devices are based on high energy varistors (MOV) matched with the DC operating voltage from
      12V to 48V DC.
    • It reacts to voltage impulses in a few nanoseconds, thus achieving a very low residual voltage,
      protecting even highly sensitive equipment.



    Product detail:



    2 Mod BR12-20
    SPD classification according to IEC61643-1 Class II
    Operating Voltage                                                        Un 12V DC
    Max. Continuous Operating Voltage                            Uc 20V DC
    Nominal discharge current (8/20us)                              In 10kA
    Max. discharge current (8/20us)                               Imax 20kA
    Voltage Protection Level                                              Up ≤320V
    Response time                                                              tA ≤25ns
    Leakage current ≤20µA
    Operating temperature range                                       Tu -40℃-80℃
    Operating state / fault indication green / red
    Protection Mode +/PE,-/PE
    Cross-section area (Min.) 4mm2
    Cross-section area (Max.) 35mm2
    For mounting on 35mm Din rail
    Enclosure material                   Thermal plastic UL94-V0
    Degree of protection IP20
    Remote Signalling Optional



    Dimension:



    Long Life 2p 12v Dc Power Supply Solar Panel Surge Protector For Solar System


    Application:

    • For use in photovoltaic systems.
    • Mainly used for DC supply lines.
    • For installation in the DC circuits of solar photovoltaic systems, string box, inverter.
    • Protect against lightning surge voltages in solar system (photovoltaic power supply system).

    Advantage:

    • Retardant materials.
    • Low protection level.
    • Low residual voltage.
    • Very fast response.
    • Easy and fast maintenance.
    • Customized logo & label printing.

    Installation:

    • These units must be installed in parallel on the dc networks to be protected.
    • It is essential to connect correctly the input and output terminals. Otherwise the SPD components will
      not work properly.
