2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD

2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD

    • 2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD
    • 2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD
  • 2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD

    Product Details:

    Place of Origin: China
    Brand Name: BRITEC
    Model Number: BRPV2-800

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 Piece/Pieces
    Packaging Details: EXPORT PACKING
    Delivery Time: Shipped in 15 days after payment
    Payment Terms: L/C, D/A, T/T, Western Union
    Supply Ability: 50000 Piece/Pieces Month
    Contact Now
    Detailed Product Description
    Place Of Origin: Zhejiang, China (Mainland) Type: Solar Surge Protector
    Model Number: BRPV2-800 Item Name: DC Surge Protector
    Material: Thermal Plastic Ucpv: 800v
    Pole Number: 2P Tu: -40℃-80℃
    In: 20kA Standard: IEC61643-11

    High Quality 2p DC Surge Protector 20-40kA PV Lightning Arrester 800v SPD


    Characteristic:


    • Type: Surge protector.
    • UP: <3.0KV.
    • Number of poles: 2.
    • Signal indication device.
    • Input voltage: ~800VDC.
    • Nominal Discharge Current: 20KA.
    • Max. Discharge Current: 40KA.
    • Inside over-current and over-heat protection, temperature control open circuit.



    Product detail:


    2 ModBRPV2-800
    SPD classification according to EN61643-11Type 2
    SPD classification according to EN50539-11Class II
    Max. continuous operating dc voltage                          Ucpv800V
    Nominal discharge current (8/20us)                                  In20kA
    Max. discharge current (8/20us)                                   Imax40kA
    Voltage protection level [(DC+/DC-)→PE]                       Up≤3.0kV
    Response time                                                                  tA≤25ns
    Operating temperature range                                           Tu-40℃-80℃
    Operating state / fault indicationgreen / red
    Cross-section area (Min.)4mm2
    Cross-section area (Max.)35mm2
    For mounting on35mm Din rail
    Enclosure material                Thermal plastic UL94-V0
    Degree of protectionIP20


    Dimension:

    2 P DC Surge Protection Device 20-40kA PV Lightning Arrester 800v SPD


    Application:

    • Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltage.
    • Applied to provide fine overvoltage protection of electronic equipment whose power is supplied by
      direct-current power supply.

    Advantage:

    • Long work life.
    • Retardant material.
    • Stable performance.
    • Simple maintenance.
    • Large intake capacity.
    • Extremely quick respond.
    • Module design, convenient installation.
    • High quality pressure sensitive resistance.

    FAQ:

    • Q: Do you have any certificates?
       A: We have CE, TUV, CB, Intertek, and ISO9001 Certification.

    • Q: How about your products quality inspection?
       A: We have professional QA and QC teams, 100% quality inspection is performed before goods out
           of factory.

    • Q: Can you accept to use our logo?
       A: we accept OEM production and can make customized product.
