Fireproof AC 385V 25kA 1+1 BR-25GR Surge Protection Device

Fireproof AC 385V 25kA 1+1 BR-25GR Surge Protection Device

  • Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device
  • Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device
Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device
Product Details:
Place of Origin: China
Brand Name: BRITEC
Certification: TUV
Model Number: BR-25GR 1+1
Payment & Shipping Terms:
Minimum Order Quantity: 100 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: Shipped in 15 days after payment
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 50000 Piece/Pieces Month
Contact Now
Detailed Product Description
Item Name: Surge Protective Type: Ac Surge Protector
Pole Number: 1+1 Uc: 385V
Iimp: 25kA In: 25kA
Protection: IP20 Tu: -40℃-80℃
Material: Plastic Model: BR-25GR 1+1
High Light:

BR-25GR Surge Protection Device

,

BR-25GR surge arrester protection

,

25kA Surge Protection Device

25KA ~385V Surge Protector AC Protection Surge Protective BR-25GR 1+1



AC Protection Surge Protective Features:

This is a kind of fine quality surge protecting device, fire proof and corrosion-resistant. Quickly react speed with strong bearing capacity.
Simple and easy to use. More reliable and more safety.
Working status indicating window, red means failure, which can effectively react the working status in time.
Surge protect, prevents home electric network receive excessive impact while lightening.
Detachable 35mm Din rail installation design.


AC Protection Surge Protective Technology characteristic:



Specification BR-25GR 1+1
Item name Surge Arrester
SPD dassification according to EN61643-11 Type 1
SPD dassification according to EN61643-11 Class I
Max continuous 0perating a.c. voltage                 Uc 385V/255V
Lightning impulse current (10/350µs)                 limp 25kA/50kA
Norminal discharge current (8/20µs)                     In 25kA/50kA
Voltage protection level                                        Up ≤1.5kV
Follow current extinguishing capability a.c.           lifi 25kA rms/100A rms
Max. backup fuse 315A gL
Response time                                                      tA ≤100ns
For mounting on 35mm Din rail
Degree of protection IP20
Payment term 30% deposit in advance,70% before shipment,100% T/T in advance
Certificate CB/CE/ROHS/ISO9001
Logo Customized logo available
Design ability We can supply sample,OEM&ODM is welcome (Design,Engineering, Photographing,Sample, Production)



Dimension:



Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device 0



AC Protection Surge Protective Product Description:

Surge voltage protector SPD lightning protection device AC surge protective BR-25GR series of spark gap surge protector belonging to (hereinafter referred to as SPD) are suitable for AC 50 / 60Hz, rated voltage up to 385v TT, TN-S and other power supply system, it protect to indirect and direct lightning effect or other transient over voltage. SPD design according with GB18802.1/IEC61643-1 standard.

AC Protection Surge Protective Advantage:

100% Brand new and high quality.
Excellent quality, fast delivery, simple after-sales. We make every effort to provide customers with satisfactory service.
90% conventional orders will be delivered within 15-25 days.



Certification:



Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device 1



Company information:



Holding over 17 Years of Experience. Wenzhou Britec Electric Co. Ltd has been developing, producing and marketing SPDs for more than 17 years. Our product range includes AC surge protector, DC solar surge protection device, data SPDs, Led lightning arrester etc. We have designers to keep our catalog updated. Our experienced designs are the reasons why retailers and distributors from the Europe come to us. Orders Delivered in 15 to 30 Days. We deliver your off-the-shelf and OEM orders in 15 to 30 days. We have QC inspectors to assure quality. In fact, our products passed TUV and CE standards. Send us an inquiry today to learn more.



Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device 2



Test laboratory:



Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device 3



Packaging & Shipping:



Fireproof  AC 385V 25kA 1+1 BR-25GR Surge Protection Device 4



FAQ:



1. What is your MOQ?

A: Usually our MOQ is 200pcs. But we accept lower quantity for your trial order. Please feel free to tell us how many pieces you need, we will calculate the cost correspondingly, hoping you can place large orders after checking quality of our products and know our service.



2. Can I get samples?

A: Sure. We usually send samples by FEDEX, UPS, TNT or DHL. If you have carrier account, it will be fine to ship with your account, if not, you can pay the freight charge to us, we will ship with our account. It takes about 5-7 days to reach.



3. How long is the sample lead time?

A: For existing samples, it takes 2-3 days. Anyway, we will response fast to your request.



4. How long is the production lead time?

A: It takes 15-30 days. We have large production capacity, which can ensure fast delivery time even for large quantity.



5. What format of the file do you need if I want my own design logo?

A: We have our own designer in house . So you can provide JPG,cdr or PDF, etc. We will make 3D drawing for mold or printing screen for your final confirmation based on technique.



6. Which kinds of certificate would you have?

A: TUV, CE, CB etc.



7. What is your payment term?

A: Our normal payment term is TT 30% deposite after order signed and 70% before shipping.
