BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester

BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester

  • BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
  • BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
  • BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
  • BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
  • BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester
Product Details:
Place of Origin: China
Brand Name: BRITEC
Certification: TUV/UL/CB/CE/ROHS/ISO9001
Model Number: BRPV3-600GD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Packaging Details: EXPORT PACKING
Delivery Time: 15-20 days after payment
Supply Ability: 10000 per week
Contact Now
Detailed Product Description
Item: GDT 600V Solar SPDs Certificate: CE,CB,IEC
Enclosure Material: Thermoplastic Condition: 100% Original
Packaging Details: Standard Export Box Package Usage: Solar Power
Packing Unit: 1 Pc Warranty: 4 Years
Color: White
High Light:

EN 50539-11 DC Surge Protection Device

,

EN 50539-11 dc 600v spd

,

remote signaling dc 600v spd

GDT 600V Solar SPDs No Leakage BRPV3-600GD DC surge protection device

GDT 600V Solar SPD Feature:

• Protects equipment against induced overvoltage caused by lightning strikes or switching transients.

• Visual indication of varistor status – Healthy/Replace

• Contact for remote signaling of varistor status.

• Replaceable modules with colour code: white for varistor

• Complies with EN 50539-11:2010

• 35 mm rail (EN 60715) mounting

GDT 600V Solar SPD Product Details:
BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 0

  BRPV3 600 GD
SPD classification according to EN61643-11Type 2
SPD classification according to EN50539-11Class II
Max. continuous operating dc voltage                            Ucpv600V
Nominal discharge current (8/20us)                                    In20kA
Max. discharge current (8/20us)                                     Imax40kA
Voltage protection level [(DC+/DC-)→PE]                         Up≤2.6kV
Response time                                                                             tA≤25ns
Operating temperature range                                             Tu-40℃-80℃
Operating state / fault indicationgreen / red
Cross-section area (Min.)4mm2
Cross-section area (Max.)35mm2
For mounting on35mm Din rail
Enclosure material               Thermal plastic UL94-V0
Degree of protectionIP20


GDT 600V Solar SPD Dimension:

BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 1

SPD Type 2  for 600 V DC photovoltaic systems
• Replaceable varistor modules with colour code
• Visual and remote signalling of varistor status
• Surge arrester for protection of DC side 600 V systems in photovoltaic applications.



GDT 600V Solar SPD Advantage:

• Optical status indicator via LED.
• Space-saving enclosure with a width of only four modules for up to 600 V d.c.
• Operating state / fault indication by green / red indicator flag in the inspection window.


Our Services:


• 17 years global leading profession manufacture of electrical products surge arrester.
• All products will be well packed before shipping.
• Standard packaging, and you can also tell us your own requirements on packaging.
• Faster delivery.
• Individually Tested Prior to Shipment.


Why need surge arrester?


Large single surge events, such as lightning, can reach hundreds of thousands of volts and can cause immediate or intermittent equipment failure. Although these surges may be smaller in magnitude, they occur more frequently and with continuous exposure can degrade sensitive electronic equipment within the facility. The use of adapted surge protections is then highly recommended.


Installation instruction:


• Mount the SPD on 35 mm DIN rail.
• The SPD is placed in parallel between the energized conductors and ground.
• The selected SPD must be specifically designed, rated and approved for application on dc PV voltages.


Company profile:

Wenzhou Britec Electric Co., Ltd. is a manufacturer and exporter specialized in SPDs. Such as ac surge protector, dc surge protection, LED lighting surge arrester, data surge protective device and so on. Our company is located in Yueqing, Zhejiang, China. Convenient transportation, excellent quality and prices and good service attract customers from each place of the world. Our company culture is "sincere and trustworthy, punctuality, high - quality" Welcome every clients!
BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 2

BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 3

Our certificate:
We got CB, CE, TUV,RoHS Certificate:

BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 4

Payment:

   Payment Term   T/T      EXW         30% T/T in advance, paid the balance before shipment.
FOB
CIF   30% T/T in advance, paid the balance against copy of B/L.
L/C   L/C amount above 50,000 usd, we can accept L/C at sight.
   Paypal      Amount lower than 5000usd.
Delivery Time   15-30 days after receiving deposit.


BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 5

Factory:
BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 6

BRPV3-600GD GDT 600V DC Surge Protection Device Remote Signaling pv lightning arrester 7

FAQ:

Q1: How long is your products warranty?
  A: The warranty period of our products is 5 Years.

Q2: How about inspection?
  A: We have the whole inspection system from raw material to end products.

Q3: What is the service offered by company?
  A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement. We also have the sales team to offer good service from pre-sale to after-sale.
